AIR HEATING

QUICKLY AND COMFORTABLY A PLEASANT TEMPERATURE

Healthy air as well a quickly a pleasant temperature in your home, no matter if it is a cold or a hot day? A Brink air heating system not only heats the home, but in many cases it can also ventilate and cool it. Several modules can be combined into a system that gives the whole house excellent air as wel as a pleasant temperature.

An air heating system sends heated or cooled air throughout the home; it is energy-efficient, responds quickly and offers great comfort. The desired room temperature is reached much quicker than with under-floor or radiator heating. Moreover, it can be combined with a central heating boiler or district heating and, in a properly insulated house, also with a heat pump or even a hybrid system.

SELLING POINTS

why AIR HEATING?

  • The desired room temperature, cooler or warmer, is quickly reached and, thanks to the even air distribution, it feels very comfortable.
  • The air is diffused through barely visible air grilles in the floor or the wall.
  • Air grilles offer more space and layout freedom than radiators.
  • Just a whisper, without draught, without smells.
  • Low-energy, so lower heating costs and low CO2
  • Easy to use and little maintenance.
  • Can be flexibly integrated with Heat Recovery Ventiltion (HRV) ,(top) cooling and hot tap water. A Multi Zone control for heating.cooling and CO2 demand controlled ventilation is also possible
  • Can be combined with central heating boiler, district heating and in many cases also with a heat pump or hybrid* system.

* ask your local Brink Partner for the possibilities.

types

AIR HEATING DIRECT OR INDIRECT, WITH ANY ENERGY SOURCE

An air heater is the basis of every type of air heating. How the air heater receives its heat differs per type and can be direct, in the appliance, or indirect, from outisde the appliance. An air heating solution can be installed on gas or electricity - from the mains or solar energy - and in many cases also in combination with a central heating boiler, district heating or a heat pump.

Directly or indirectly fired
In the case of a directly fired air heater, the heat is generated in the appliance itself, by a heating element on gas or electricity.
With an indirectly fired air heater, the heat is generated in a device or system outside the air heater, for example a Brink HR central heating boiler or heat pump. Indirectly fired air heaters are compact so they are easily installed, also in smaller rooms.

Air heating and ventilation through the same ducts
All air heating systems distribute the hot or cool (upto 16 °C) air through existing air ducts, from which it enters the various habitable rooms. Our air heaters are a perfect match for our ventilation solutions. There is no need for an additional duct system, because the, warm or cool, pure air is transported by the same ducts.

Zone control
On installing the air heating, one or more, independently controllable zones can be created; for instance a division between living and sleeping zone.

play video
IN ANY SITUATION

AIR HEATING IN NEW PROJECTS, RENOVATION OR EXTENSION

Air heating is preferably used in new-build homes, but it is also available for renovation or extension. From serial construction to luxury homes, its many options make air heating accessible to all.

If the home is already equipped with ducts for heat recovery ventilation, the same ducts can be used for air heating. Hardly any additional adjustments are then required to enjoy excellently heated or cooled air in your home.

FEATURES

lotS of possibilities WITH OUR AIR HEATERS



ALLURE
ELAN 10, 16, 25 2.0
ELAN 25 3.0
ELAN 4
  direct or indirect direct indirect indirect indirect
  heating yes yes yes yes
  energy carrier gas water* water* water*
  Multi zone control
 - Multi zone control Multi zone control


Multi zone control
or by addition of stackable units
  upflow/downflow both possible**  both possible upflow sideways
  cooling
 with top cooling** with top cooling with cold water (up to 16 °C) with cold water (up to 16 °C)
  ventilation
 optional with balanced ventilation (Flair or Renovent) optional with balanced ventilation (Flair or Renovent) optional with balanced ventilation (Flair or Renovent) optional with balanced ventilation (Flair or Renovent)
  outdoor air connection
 yes - - -
  capacity (kW) 10, 16, 25, 40 10, 16 and 25 25 4
  can be combined with: (top) cooling, heat pump-chiller, balanced heat recovery ventilation, HRV (top) cooling, heat pump-chiller, balanced heat recovery ventilation, HRV heat pump-
chiller, balanced ventilation with heat recovery, HRV		 (top) cooling, heat pump-
chiller, balanced ventilation with heat recovery, HRV
  hot tap water supply
 - optional optional optional

* from Brink HRE central heating boiler, district heating or heat pump
 ** except Allure B-10 HR

Multi-zone control VOOR VERWARMING, KOELING EN VENTILATIE MET DE ELAN LUCHTVERWARMER

With Multi-zone control, each zone or habitable area, such as the living room or bedroom is fitted with a room thermostat for individual temperature control and a CO2 sensor to control ventilation automatically. The Multi-zone control ensures that heat and/or ventilation is distributed to only those rooms where it is needed. In this way you can be sure of the most excellent air quality in your home, while at the same time saving a substantial amount on energy costs, as you do not need to unnecessarily heat or provide ventilation for specific rooms.

The basis of the system is a room controller and Elan air heater that is driven by a heat source, such as a heat pump, central-heating boiler, district heating or  other sources for heating. To obtain the cleanest, most filtered air in your home, the Elan air heater can easily be expanded by adding an energy-efficient ventilation system with heat recovery (HRV), such as a Flair unit.

More information about the Multi zoneregeling? Download the leaflet





contact form

MORE information ABOUT AIR HEATING AND COOLING? WE WILL BE HAPPY TO ADVISE!
